Product Description
This 7 inch diameter taper bore electric clutch with a single groove belt can be readily mounted on pumps, compressors and more.
Clutch Specifications:
- Power: 48 Watts
- Max Speed: 5000 RPM
- Max Static Torque: 75 pound-feet
- Shaft: Taper Bore
- Belt: 2 Groove 1/2 Inch
- Pump Mount: Type "A"
Important Installation Step:
Clutches require a short burnishing period to generate the rated torque. To burnish, install the clutch and run at 1000 to 1200 RPM. Cycle on/off at the rate of 5 seconds on - 5 seconds off for a total of 25 cycles.
